Gator GRV43MKT 4.3" Mirror Mount Display Reverse Camera Kit
Gator GRV43MKT 4.3" Clip-On Mirror Mount Reverse Camera Kit
A complete reverse camera kit with a 4.3-inch display that clips over the existing rear view mirror when reverse is engaged the screen activates, when driving forward it acts as a standard mirror. PAL, IP67 butterfly mount camera, 6m cable. 1-year warranty.
Product Overview
The Gator GRV43MKT is a complete wired reverse camera kit with a 4.3-inch display integrated into a clip-on mirror housing that installs over the existing rear view mirror. The universal clip-on design fits mirrors extending from 53mm to 70mm wide, covering most passenger vehicles.
When reverse gear is engaged, the 4.3-inch screen automatically activates. When driving forward, the housing functions as a standard reflective mirror. The PAL butterfly mount camera includes built-in parking gridlines and a 6m cable with reverse trigger.
Two video inputs on the mirror monitor allow a second camera to be added.
Note on image orientation: The mirror monitor does not support a reverse (mirror) image. The camera and monitor both output in standard non-mirrored rear view orientation.
Features & Benefits
- Clip-on mirror design — installs over existing rear view mirror, no permanent modification
- 4.3-inch 480×272 display, 500cd
- Universal clip — fits mirrors 53–70mm wide
- PAL butterfly mount camera — IP67, 120 degrees, built-in parking gridlines
- 6m cable with reverse trigger
- Two video inputs — add a second or front camera
- When not reversing, acts as a standard reflective mirror
- 1-year warranty
Technical Specs
Monitor:
| Specification | Detail |
|---|---|
| Monitor Size | 4.3 inch |
| Mount Type | Clip-on rear view mirror (53–70mm width) |
| Resolution | 480(H) × 272(V) |
| Brightness | 500 candela |
| Input Voltage | 12V |
| Video Inputs | 2 (RCA) |
| Display Configuration | Single |
| Image Flip | No |
| Reverse Mirror Image | No |
| Video Standard | PAL |
| Image Adjustment | Brightness, contrast, saturation |
| Monitor Dimensions | 75mm (H) × 285mm (W) × 37mm (D) |
Camera:
| Specification | Detail |
|---|---|
| Mount Type | Butterfly surface mount |
| Camera Type | Reverse |
| Lens Angle | 120 degrees |
| Image Sensor | CMOS |
| Parking Gridlines | Yes — built in |
| Video Standard | PAL |
| IP Rating | IP67 |
| Input Voltage | 12V |
| Minimum Illumination | 0.2 lux |
| LEDs | None |
| Camera Connector | 4-pin micro DIN plug |
| Monitor Connector | RCA |
| Video Cable Length | 6m |
| Reverse Trigger on Cable | Yes |
| Camera Dimensions | 18mm (H) × 38mm (W) × 30mm (L) |
Kit:
| Specification | Detail |
|---|---|
| Connection Type | Wired |
| Warranty | 1 year |
Compatible With / Goes Well With
Direct Vehicle Fit:
- Universal — fits most vehicles with a rear view mirror between 53mm and 70mm wide
Goes Well With:
- Second or front view camera (for the spare second RCA input)
- Gator GRCANFLT CANBUS filter (for CANBUS vehicles experiencing interference)
Frequently Asked Questions
How does the clip-on mirror install?
The GRV43MKT housing clips over the existing factory rear view mirror — secured by an elastic/clip mechanism. It does not replace the mirror; the factory mirror remains in place underneath. When the reverse camera is not active, the clip-on housing acts as a standard reflective mirror.
What mirror sizes does this clip fit?
The clip-on design fits rear view mirrors extending 53mm to 70mm in width — covering the majority of passenger cars and light commercial vehicles. Confirm your mirror dimensions before purchasing if you are unsure.
Does the display support a mirrored reverse image?
No. The GRV43MKT monitor does not support a reverse (mirror) image. The camera and monitor both output standard non-mirrored rear view orientation.
Can a second camera be connected to this system?
Yes. The mirror monitor has two RCA video inputs — a second camera can be added and used with the second input.
Is this kit PAL or NTSC?
Both the camera and monitor are PAL — the GRV43MKT is a PAL-only kit, suited to Australian vehicles and PAL aftermarket head units.
