LED Autolamps 110RMG 10/30V LED Stop/Tail Lamp With Grommet and Plug
ADR 49/00 Approved 10/30V Stop/Tail Lamp with Grommet and Plug 130mm Recessed, IP67
Product Overview
The LED Autolamps 110RMG is a 10/30V LED stop/tail lamp designed for flush recessed mounting on trailers, trucks, and commercial vehicles. At 130mm round and 12mm deep with a plastic base, it is supplied with a grommet and plug for a complete, sealed recessed installation. The 3-pin connector is not included and must be sourced separately.
ADR 49/00 compliant and rated IP67, drawing 0.31A at 13.8V. The stop/tail companion to the 110AMB indicator lamp in the 130mm round recessed series. Backed by a 5-year warranty.
Features & Benefits
- Grommet and plug included — complete sealed installation kit for a weatherproof recessed fit straight out of the pack
- Low-profile flush recessed mount — 12mm depth sits flush with the panel for a clean, integrated finish
- ADR 49/00 compliant — meets Australian Design Rules for legal on-road use as a stop/tail lamp
- IP67 rated — fully sealed against dust and water immersion, built for exposed outdoor and transport environments
- 3-pin plug and cable connector — note: 3-pin connector not supplied; must be sourced separately
- Low current draw — 0.31A at 13.8V for efficient operation across multi-lamp trailer builds
- 10/30V multi-voltage — compatible with 12V light vehicles through to 24V and 28V heavy transport without modification
- Plastic base — lightweight, corrosion-free housing suited to trailer and truck body panel mounting
Technical Specs
| Specification | Detail |
|---|---|
| SKU | 110RMG |
| Lamp Type | Stop / Tail |
| Voltage Range | 10V – 30V |
| Diameter | 130mm |
| Depth | 12mm |
| Current Draw | 0.31A @ 13.8V |
| Base Material | Plastic |
| Mounting | Flush recessed |
| Connector | 3-pin plug and cable (connector not supplied) |
| Included Accessories | Grommet, plug |
| Protection Rating | IP67 |
| Compliance | ADR 49/00 |
| Weight | 0.5 kg |
Compatible With / Goes Well With
- Trailers, trucks, and commercial vehicles requiring flush-mount stop/tail lamps with grommet
- 12V light vehicles and 24V/28V heavy transport applications
- Trailer builds requiring ADR-approved stop/tail lighting
- LED Autolamps 110AMB indicator lamp (same 130mm round recessed form factor)
- LED Autolamps 110WMG reverse lamp (same 130mm round recessed form factor)
- LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
Is the 110RMG approved for road use in Australia?
Yes. The 110RMG is ADR 49/00 compliant, meeting Australian Design Rules requirements for legal on-road use as a stop/tail lamp.
What accessories are included with the 110RMG?
The pack includes a grommet and plug for a complete, sealed recessed installation. The 3-pin connector is not included and must be sourced separately.
How does the 110RMG compare to the 110RMB stop/tail lamp?
The 110RMG includes a grommet and plug for a sealed recessed installation, making it ready to fit straight out of the pack. The 110RMB is the same lamp in the same form factor without grommet accessories.
What is the IP rating on the 110RMG?
The 110RMG is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer and truck body mounting.
What warranty does the 110RMG carry?
Not specified in available supplier data — confirm with LED Autolamps or F.A.E. before publishing.
Weight
0.5 kg
Original: $86.58
-65%$86.58
$30.30Product Information
