LED Autolamps 7515WB 12V LED Interior Lamp Cool White Bezel
12V Round Interior Lamp White Bezel, 15 LEDs, 250lm, 6500K Cool White, 9mm Low Profile, Poly Bag.
Product Overview
The LED Autolamps 7515WB is a 12V round interior lamp from the 7515 Series a compact, ultra-low-profile interior dome light measuring ø76mm diameter x 9mm deep with a white bezel. The 7515 Series features 15 high-brightness LEDs, low profile of only 9mm, 250 effective lumens, cool white 6500K output, 12V only, and a 3-year warranty.
The current draw is 0.27A at 13.8V with 230lm raw / 180lm effective output. The housing is ABS with a polypropylene lens, and a 20cm cable is provided. Installation: remove the bezel and surface mount using three screw points, run wires through hole in mounting surface and refit bezel by clicking into place.
The "WB" suffix indicates white bezel / bulk poly bag supply. The single blister version is the 7515W. The chrome bezel poly bag version is the 7515CB. Backed by LED Autolamps' 3-year warranty.
Key Specifications
- LED count: 15
- Lumen output: 250lm effective (230lm raw / 180lm effective per AE.Parts)
- Colour temperature: 6500K cool white
- Bezel colour: White
- Diameter: ø76mm
- Depth: 9mm
- Cable: 20cm
- Mount type: Surface mount 3-screw fix, click-back bezel
- Current draw: 0.27A @ 13.8V
- Housing: ABS
- Lens: Polypropylene
- Input voltage: 12V only
- Compliance: CE, ECE R10
- Warranty: 3 years
- Packaging: Poly bag (bulk)
- Brand: LED Autolamps
- SKU: 7515WB
Features & Benefits
- Ultra-slim 9mm depth: At just 9mm, the 7515 Series is one of the slimmest round interior dome lights available ideal for low-ceiling applications in caravans, motorhomes, trucks, and boats
- 15 high-brightness LEDs: 15 LEDs delivering 250 effective lumens for bright interior illumination
- 6500K cool white: Crisp daylight-style output for clear, well-lit interior spaces
- White bezel: Bright white bezel suits light-coloured interior trim in caravans and motorhomes; chrome bezel alternative is the 7515CB
- Click-back bezel: Remove bezel, surface mount with three screws, refit bezel by clicking into place clean concealed-fastener installation
- 20cm cable: Short fly-lead pre-wired for connection to switched power supply
- Poly bag supply: Individual bulk poly bag packaging for trade and workshop supply
- 0.27A current draw: Low 0.27A draw at 13.8V for efficient interior lighting
- 3-year warranty: Backed by LED Autolamps' 3-year warranty
Technical Specs
| Specification | Detail |
|---|---|
| SKU | 7515WB |
| Brand | LED Autolamps |
| Series | 7515 Series |
| LED Count | 15 |
| Effective Lumens | 250lm (230lm raw / 180lm effective) |
| Colour Temperature | 6500K Cool White |
| Bezel Colour | White |
| Diameter | ø76mm |
| Depth | 9mm |
| Cable Length | 20cm |
| Current Draw | 0.27A @ 13.8V |
| Housing | ABS |
| Lens | Polypropylene |
| Mount Type | Surface mount 3-screw, click-back bezel |
| Input Voltage | 12V only |
| Compliance | CE, ECE R10 |
| Warranty | 3 Years |
| Packaging | Poly bag (bulk) |
Compatible With
Suits all 12V interior applications requiring a slim round dome light:
- Caravans and motorhomes
- Truck cabs and commercial vehicle interiors
- Marine and boat cabins
- Camper trailers and campervans
Frequently Asked Questions
What is the difference between the 7515WB and the 7515W?
Both are the same 7515 Series white bezel cool white interior lamp. The 7515WB is supplied in a poly bag (bulk) while the 7515W is in a single retail blister pack.
What is the current draw?
0.27A at 13.8V.
Does this lamp include a switch?
No the 7515WB has a 20cm fly-lead for connection to a switched circuit. A switch or switched circuit must be provided separately.
What diameter is this lamp?
ø76mm diameter, 9mm depth.
What is the return policy for this product?
Return eligibility is subject to the retailer's policy. Contact the seller before ordering if you have any questions.
