Roadvision RWL5280F LED Work Light 120W Square Flood Beam Osram
Roadvision RWL5280F LED Work Light 120W Square Flood Beam Osram
A high output square 120W LED work lamp from the Roadvision RWL52 Series, the RWL5280F produces up to 9831 maximum lumens from 36 x 5W Osram LEDs through a flood beam, with Thermal Management Technology, 10-30V DC multi-volt input, die-cast aluminium housing, polycarbonate lens, 2-pin Deutsch plug wiring, and a 5-year warranty.
Product Overview
The Roadvision RWL5280F is the highest output work lamp in the RWL52 Series, packing 36 x 5W Osram LEDs into the same compact 118 x 132 x 74mm square body as the 45W models. Producing up to 9831 maximum lumens through a flood beam pattern rated at 110 lux at 10 metres, it delivers serious wide-area illumination for machinery, trucks, agricultural equipment, and work sites.
The RWL5280F is equipped with Thermal Management Technology, and the lightweight, tough die-cast aluminium housing and polycarbonate lens allow for worry-free operation in even the toughest conditions. The multi-volt 10-30V DC input draws 10.0 amps at 13.8V, and solid-state technology delivers a 50,000 hour LED lifespan. Installation is a simple 2-wire connection via the 2-pin Deutsch plug, with over/under voltage protection, reverse polarity protection, and EMI/EMC radio interference approval built in.
Features & Benefits
120W Square Flood Beam - Up to 9831 Lumens: The RWL5280F produces up to 9831 maximum lumens through a flood beam pattern rated at 110 lux at 10 metres, the highest output in the RWL52 Series for serious wide-area illumination.
36 x 5W Osram LEDs: Thirty-six 5W Osram LEDs deliver high performance light output with the energy efficiency and reliability of quality LED componentry.
Compact Body, Maximum Output: The RWL5280F packs 120W of output into the same 118 x 132 x 74mm body as the 45W models in the series, keeping mounting requirements compact despite the output.
Thermal Management Technology: Built-in Thermal Management Technology protects the lamp and maintains performance in demanding operating conditions.
50,000 Hour LED Lifespan: Solid-state technology delivers a 50,000 hour LED lifespan for maintenance-free performance over the long service life typical of machinery and work vehicle applications.
Die-Cast Aluminium Housing with Polycarbonate Lens: The lightweight, tough die-cast aluminium housing and polycarbonate lens allow worry-free operation in even the toughest conditions.
Waterproof Construction: The RWL5280F features waterproof construction suited to external mounting in wet and muddy conditions.
Multi-Volt 10-30V DC Input: The 10-30V DC multi-volt input makes the RWL5280F compatible with both 12V and 24V vehicle electrical systems, drawing 10.0 amps at 13.8V.
Simple 2-Wire Installation with Deutsch Plug: The 2-pin Deutsch plug and simple 2-wire installation make for a quick, professional connection, with over/under voltage protection, reverse polarity protection, and EMI/EMC radio interference approval built in.
5-Year Warranty: The RWL5280F is backed by a 5-year Roadvision warranty.
Technical Specs
| Specification | Detail |
|---|---|
| SKU | RWL5280F |
| Brand | Roadvision |
| Series | RWL52 |
| Description | Work Lamp LED 120W Square Flood Beam |
| Beam Type | Flood Beam |
| Maximum Lumens | 9831lm |
| Maximum Watts | 120W |
| Light Source | 36 x 5W Osram LEDs |
| Lux at 10m | 110 Lux |
| Input Voltage | 10-30V DC |
| Current Draw | 10.0A at 13.8V DC |
| Lens | Polycarbonate |
| Housing | Die-Cast Aluminium |
| Ingress Protection | Waterproof (IP Rating Not Specified) |
| Wiring | 2 Pin Deutsch Plug |
| Dimensions | 118 x 132 x 74mm |
| LED Lifespan | 50,000 Hours |
| Warranty | 5 Years |
Compatible With
The RWL5280F is compatible with 10-30V DC vehicle electrical systems, covering both 12V and 24V vehicles. The RWL52 Series is also available in 45W flood beam (RWL5246F) and 45W spot beam (RWL5246S) versions in the same body size. Given the 10.0A draw at 13.8V, confirm your circuit and switch capacity along with mounting space before purchase.
Frequently Asked Questions
How bright is the RWL5280F?
The RWL5280F produces up to 9831 maximum lumens from 36 x 5W Osram LEDs, rated at 110 lux at 10 metres through a flood beam pattern, making it the highest output lamp in the RWL52 Series.
What is the difference between the RWL5280F and RWL5246F?
Both share the same 118 x 132 x 74mm body and flood beam pattern. The RWL5280F runs 36 LEDs at 120W for up to 9831 lumens and 110 lux at 10 metres, while the RWL5246F runs 9 LEDs at 45W for up to 3756 lumens and 40 lux at 10 metres.
Is the RWL5280F compatible with 24V vehicles?
Yes. The RWL5280F operates across 10-30V DC, making it compatible with both 12V and 24V vehicle electrical systems.
What is the current draw of the RWL5280F?
The RWL5280F draws 10.0 amps at 13.8V DC, so confirm your wiring, fusing, and switch capacity are rated accordingly before installation.
How does the RWL5280F connect to the vehicle?
The RWL5280F uses a 2-pin Deutsch plug with simple 2-wire installation, and includes over/under voltage protection, reverse polarity protection, and EMI/EMC radio interference approval.
